xiii
Figures
FIGURE P-1 Link to Multimedia Instructions xxi
FIGURE 1-1 Sun Blade 150 System 1–2
FIGURE 1-2 Front Panel Overview 1–5
FIGURE 1-3 Back Panel Overview 1–5
FIGURE 1-4 Sun Blade 150 System Replaceable Parts 1–7
FIGURE 3-1 Setting Up a TIP Connection 3–3
FIGURE 5-1 Front Panel Power Switch 5–5
FIGURE 5-2 Removing the System Cover 5–6
FIGURE 5-3 Attaching the Wrist Strap to the Chassis 5–7
FIGURE 6-1 Removing and Replacing the Power Supply 6–2
FIGURE 6-2 Removing and Replacing the Diskette Drive Data Cable Assembly 6–4
FIGURE 6-3 Removing and Replacing the Diskette Drive Power Cable Assembly 6–5
FIGURE 6-4 Removing and Replacing the Primary IDE Cable Assembly 6–7
FIGURE 6-5 Removing and Replacing the Secondary IDE Cable Assembly 6–8
FIGURE 6-6 Removing and Replacing the Smart Card Reader Cable Assembly 6–9
FIGURE 6-7 Removing the Front Bezel 6–11
FIGURE 6-8 Removing and Replacing the Power Switch/LED Assembly 6–12
FIGURE 6-9 Removing and Replacing the Speaker Assembly 6–14
FIGURE 6-10 Removing and Replacing the Fan Assembly 6–16
FIGURE 7-1 Removing and Replacing the Peripheral Assembly 7–2
