SVAN 971 User Manual – Appendixes
123
mm – minute
58
Pause[4]
Programmable pause no. 4.
59
PauseBegin[4]
The start time of the pause no. 4 in format 0xhhmm
hh – hour
mm – minute
60
PauseEnd[4]
The end time of the pause no. 4 in format 0xhhmm:
hh – hour
mm – minute
61
Pause[5]
Programmable pause no. 5.
62
PauseBegin[5]
The start time of the pause no. 5 in format 0xhhmm
hh – hour
mm – minute
63
PauseEnd[5]
The end time of the pause no. 5 in format 0xhhmm:
hh – hour
mm – minute
…
Table B.1.7. MEASURE TRIGGER parameters
Word
number
Name
Comment
0
0xnn2B
[2B, nn=block’s length]
1
TriggerMode
trigger mode:
0 - OFF,
2 - measurement on trigger SLOPE+
3 - measurement on trigger SLOPE–
4 - measurement on trigger LEVEL+
5 - measurement on trigger LEVEL–
6 - measurement on trigger GRAD+
2
TriggerSource
source of the triggering signal:
0 - Leq(1) the Leq result from the first profile
3
TriggerLevel
level of triggering:
24 ÷ 136 dB (*10)
4
TriggerGrad
gradient of triggering:
1 dB/ms ÷ 100 dB/ms (*10)
5
TriggerPre
reserved
6
TriggerPost
reserved
7
TriggerSampling
reserved
8
TriggerRecTime
reserved
9
TriggerStep
trigger period given in 0.1 ms. If zero Step is equal to logger time-
step (cf. Tab. B.1.15)
10
TriggerFilter
reserved
11
BitsPerSample
reserved
…
