12.6 LOGGING RESULTS IN A FILE - LOGGER RESULTS
The Logger Res. list enables activating results for three independent profiles,
which will be recorded to the logger file during the measurement: Lpk, Lmax,
Lmin, Leq and LAV.
12.7 DISPLAYING DOSIMETER RESULTS
In the Dose Meter function, next results are measured
and displayed: OVL, Lpeak, Lmax, Lmin, L, DOSE,
D_8h, PrDOSE, LAV, Leq, LE, SEL8, E, E_8h, LEPd,
PSEL, Ltm3, Ltm5, Lnn, PTC, PTP, ULT, TWA,
PrTWA, Lc-a;
12.7.1 Displaying of Leq & Lav results – Leq & Lav – Leq & Lav
The Leq & Lav position enables selecting the mode of
displaying the Leq and Lav results.
If Both is selected Leq and Lav are always displayed
together.
If Mutual Exclusive is selected, the rule is:
- for Exchange Rate equal to 3, Leq is displayed
and Lav is not;
- for Exchange Rate other than 3, Lav is
displayed and Leq is not.
