C.2 SPECIFICATION OF SVAN 971 AS 1/1 OCTAVE AND 1/3 OCTAVE ANALYZER
The SVAN 971 instrument can operate as 1/1 Octave or 1/3 Octave analyzer conforms to the international
standards IEC 61260-1:2014 standard for the pass band filters.
Note: Simultaneously to the frequency analysis SVAN 971 operates as a Sound Level Meter!
See Chapters C.1 for specification.
Signal input
● SV18 preamplifier throughout ST02 adapter
● Maximum input voltage: SVAN 971 meets the requirements IEC 348 for the 2
nd
class device. The input
voltage shall not exceed the limits between -10 V and +10 V.
● Impedance: 10 G / 2 pF.
Linear Operating Ranges
Two measuring ranges “LOW” and "HIGH"
Table C.2.1. Linear operating range
Range
Linear operating range (with 10 dB margin from noise)
(RMS for the sinusoidal signal at reference conditions @ 1 kHz,
0.0 dB calibration factor)
LOW
from 9 μV
RMS
“A”-weighting
to 0.99 V
RMS
“A”-weighting
LOW
from 9 μV
RMS
“B”-weighting
to 0.99 V
RMS
“B”-weighting
LOW
from 9 μV
RMS
“C”-weighting
to 0.99 V
RMS
“C”-weighting
LOW
from 22 μV
RMS
“Z”-weighting
to 0.99 V
RMS
“Z”-weighting
HIGH
from 22 μV
RMS
“A”-weighting
to 4.96 V
RMS
“A”-weighting
HIGH
from 22 μV
RMS
“B”-weighting
to 4.96 V
RMS
“B”-weighting
HIGH
from 22 μV
RMS
“C”-weighting
to 4.96 V
RMS
“C”-weighting
HIGH
from 56 μV
RMS
“Z”-weighting
to 4.96 V
RMS
“Z”-weighting
Table C.2.2. Table C.3.2 Peak for the sinusoidal signal 1 kHz, at reference conditions
Peak for the sinusoidal signal 1 kHz, at reference conditions
@ 1 kHz (0.0 dB calibration factor)
Range
Max Peak value
LOW
1.4 V “A”–weighting
LOW
1.4 V “B”–weighting
LOW
1.4 V “C”-weighting
LOW
1.4 V “Z”-weighting
HIGH
7 V “A”-weighting
HIGH
7 V “B”–weighting
HIGH
7 V “C”-weighting
HIGH
7 V “Z”-weighting
