Note: For the signals with the crest factor n > 1.41 upper measuring range of the RMS is
reduced. The valid upper limit can be calculated according to the below given formula:
, where A is the upper limit for the sinusoidal signal
Example: For the crest factor n = 10 the upper limit is A10 = 120 dB.
Measuring frequency range 10 Hz ÷ 22.4 kHz with the Z filter (-3 dB)
Maximum peak voltage 20 V Peak-Peak (Maximum peak voltage of input sinusoidal
signal, which can be lead to the SLM without destruction the
meter)
RMS detector
• Digital “True RMS“ with Peak detection
• Resolution 0.1 dB
• Range 327.7 dB
• Crest Factor unlimited (for signals in 20 kHz band)
Reference conditions
• Reference frequency 1000 Hz
• Reference level 114dB
• Reference temperature +20°C
• Reference relative humidity 65 %
Calibration (electrical)
Calibration level 0.5 V
RMS
Basic accuracy < 0.2 dB (for the temperature T=+23°C 5°C for sinusoidal
signal 120 dB
RMS
in the band 10 Hz ÷ 20 kHz with the HP input
filter)
Measurement error in the full temperature range
< 0.1 dB when the temperature is from -10°C to +50°C
for the sinusoidal signal 120 dB
RMS
in the band 10 Hz ÷
20 kHz with the Z input filter.
Overload detector
The instrument has the built-in overload detectors. The overload in the measurement channel (in its analogue
part) and the overload of the analogue / digital converter are both detected. The “overload” indication is when
the input signal amplitude is 0.5 dB above the declared “Peak measurement range”
Warm-up time 1 min. (for 0.1 dB accuracy).
Effect of humidity < 0.5 dB (for 30%<RH<90% at 40C re Reference conditions).
Effect of magnetic field < 15 dB (A) or < 25 dB (Z) (for 80 A/m and 50 Hz).
Effect of Vibration < 0.1 dB (from 20 Hz to 1000 Hz at 1 m/s
2
).
