SVAN 971 User Manual – Appendixes
136
2..3
Histogram[3][1]
the first counter in the third profile
4..5
Histogram[3][2]
the second counter in the third profile
.....
.....
.....
Table B.1.23. SETUP file
Word
number
Name
Comment
0
0x0020
[20, 00=block’s length in the second word]
1
BlockLength
length of the block
2..BlockLen
gth-1
SetupTextData
saved setup values
Table B.1.24. File-end-marker
Word
number
Name
Comment
0
0xFFFF
file end marker
B.2 STRUCTURE OF THE FILE CONTAINING RESULTS FROM LOGGER’S FILE
SvanPC file header - cf. Tab. B.1.1.
File header - cf. Tab. B.1.2.
Unit and software specification - cf. Tab. B.1.3.
Calibration settings - cf. Tab. B.1.4.
USER’S text - cf. Tab. B.1.5.
Parameters and global settings - cf. Tab. B.1.6.
MEASUREMENT TRIGGER settings - cf. Tab. B.1.7.
LOGGER TRIGGER settings - cf. Tab. B.1.8.
Time-domain signal recording parameters - cf. Tab. B.1.9.
Wave-file recording parameters - cf. Tab. B.1.10.
Special settings for profiles - cf. Tab. B.1.12.
Display settings of the main results - cf. Tab. B.1.13.
Header of the statistical analysis - cf. Tab. B.1.14.
Header of the file from the logger - cf. Tab. B.1.15.
Contents of the file from the logger - cf. Tab. B.1.16. and the description in B.2.1.
B.2.1. The contents of the files in the logger
The records with the results and the records with the state of the markers as well as the records with the
breaks in the results registration are saved in the files in the logger. All results are written in dB*100.
