SVAN 971 User Manual – Appendixes
126
10
TriggerFilter
filter type:
1 - Z,
2 - A,
3 - C
5 - B
11
BitsPerSample
bits/sample: 16
…
Table B.1.12. Special settings for profiles
Word
number
Name
Comment
0
0xnn05
[05, nn=block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm06
[06, mm=sub-block’s length]
3
DetectorP[1]
detector type in the 1
st
profile:
0 - IMP.,
1 - FAST,
2 - SLOW
4
FilterP[1]
filter type in the 1
st
profile:
1 - Z,
2 - A,
3 - C
5 – B
6 – LF
5
BufferP[1]
logger contents in the 1
st
profile defined as a sum of:
0 - none,
1 - Lxpeak
1
2 - Lxymax
2
4 - Lxymin
2
8 - Lxyeq
23
16 - LAV
32 - LR15
64 - LR60
6
FilterPeakP[1]
filter type for Peak result calculation in the 1
st
profile:
1 - Z,
2 - A,
3 - C
5 – B
6 – LF
7
reserved
reserved
