SVAN 971 User Manual – Appendixes
129
27
LR60
0 – LR60 result not displayed, 1 - LR60 result displayed
28
LCA
0 – Lc-a result not displayed, 1 – Lc-a result displayed
29
OVL
0 – OVL result not displayed, 1 - OVL result displayed
30
LeqLF
0 – LeqLF result not displayed, 1 - LeqLF result displayed
…
…
…
1
x - depends of the filter type for Peak result calculation in selected profile: A, C, Z, B (cf.
Tab. B.1.12)
2
x - depends of the filter type in selected profile: A, C, Z, B, LF (cf. Tab. B.1.12)
y - depends of the detector type in selected profile: I (imp.), F (fast), S (slow) (cf. Tab. B.1.12)
3
y - only for exponential detector's type (cf. Tab. B.1.6)
Table B.1.14. Header of the statistical analysis
Word
number
Name
Comment
0
0xnn09
[09, nn=block’s length]
1
0x0307
[03=number of profiles, 07=active profiles mask]
2
0xmm0A
[0A, mm=sub-block’s length]
3
NofClasses[1]
number of classes in the first profile (120)
4
BottomClass[1]
bottom class boundary (*10 dB) in the first profile
5
ClassWidth[1]
class width (*10 dB) in the first profile
6
0xmm0A
[0A, mm=sub-block’s length]
7
NofClasses[2]
number of classes in the second profile (120)
8
BottomClass[2]
bottom class boundary (*10 dB) in the second profile
9
ClassWidth[2]
class width (*10 dB) in the second profile
10
0xmm0A
[0A, mm=sub-block’s length]
11
NofClasses[3]
number of classes in the third profile (120)
12
BottomClass[3]
bottom class boundary (*10 dB) in the third profile
13
ClassWidth[3]
class width (*10 dB) in the third profile
…
…
…
Table B.1.15. Header of the file from the logger
Word
number
Name
Comment
0
0xnn0F
[0F, nn=header’s length]
1
BuffTSec
logger time step - full seconds part
2
BuffTMilisec
logger time step - milliseconds part
