SVAN 971 User Manual
60
If no measurements were performed the next message is displayed.
The message about the time limit is displayed if the printer (or a PC) is not
connected or there is any other reason that it does not receive data. The
instrument waits for the reaction of the user (any key should be pressed except
<Shift>) and after pressing a key it returns to the Report list.
Below is an example printout of the report.
SVANTEK (C) SVAN 971 S/N:39039
2017-05-22 13:59:24 T:00:00:05
Profile 1 Slow A
LCpeak: 82.9 Ld : 55.9
LASmax: 77.0 LEPd : 55.9
LASmin: 58.8 Ltm3 : 74.2
LAS : 58.8 Ltm5 : 77.0
LAeq : 55.9 OVL : 0.0
LAE : 62.9
Profile 2 Slow C
LCpeak: 82.9 Ld : 60.8
LCFmax: 80.0 LEPd : 60.8
LCFmin: 53.3 Ltm3 : 77.2
LCF : 60.3 Ltm5 : 80.0
LCeq : 60.8 OVL : 0.0
LCE : 67.8
Profile 3 Slow Z
LZpeak: 83.3 Ld : 68.7
LZFmax: 81.4 LEPd : 68.7
LZFmin: 60.1 Ltm3 : 78.8
LZF : 65.6 Ltm5 : 81.4
LZeq : 68.7 OVL : 0.0
LZE : 75.7
