SVAN 971 User Manual
93
Spectrum view
Mode of presentation of different spectra:
1/1 Octave, 1/3 Octave and FFT.
Manual
6.1, 11.3
Display Scale
Settings of parameters of the results presentation:
Dynamics, Grid and Autoscale.
Manual
6.2
Dynamics
Range of the plot scale: 10 dB, 20 dB, 40 dB, 80 dB,
100 dB and 120 dB.
Manual
6.2
Grid
Grid swither On or Off during time history or
spectrum presentation.
Manual
6.2
Autoscale
Automatic scale adjustment of the Y axis switcher
On or Off during time history or spectrum
presentation.
Manual
6.2
Measurement
Results
Selection of the Sound Level Meter or Dose Meter
results, which will be presented on the display.
Manual
6.3
SLM Results
Selection of the Sound Level Meter results, which
will be presented on the display.
Manual
6.3
Dosimeter
Results
Selection of the Dose Meter results, which will be
presented on the display.
Manual
6.3
