100 WEB Interface
CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686) ID: um_t2gateway
This page allows configuration of the IP parameters for the IP input and shows detailed IP
status information for the input.
The IP RX Parameters field:
Enable
This shows whether the input is currently enabled. The input is enabled or disabled by
clicking the check box and then apply.
Receive port
The UDP port on which this input will listen for data.
Presumed jitter
The maximum amount of jitter you expect on the ip link. This value controls the amount
of buffering that will be applied.
Join multicast
If this box is checked the input will join the multicast configured in the following IP field.
If the box is not checked the input will listen for unicast traffic.
Multicast group addr
This parameter is only used if the “Join multicast” box is checked. This is the multicast
group the input will join.
Multicast source addr
This parameter will only be used if the input is set to join a multicast and the unit is cur-
rently using IGMP v3. If this parameter is set to something different from 255.255.255.255
or 0.0.0.0, the input will only accept multicast traffic from the IP address specified in this
parameter.
Source interface
The interface on which this input will listen for data.
The IP RX Status field:
Locked
“Yes”, when the unit has locked to the input stream and has correctly estimated the bitrate
of the input stream. “No”, when the unit has not been able to receive the input stream
correctly.
Last IP source
The source IP address of the last IP stream received by this input. If the input has never
received an IP stream this value is set to 0.0.0.0.
Total rate
The total IP rate received on this input.
Latency
This parameter reflects the network jitter the unit can handle at the moment.
Min/Max latency
This shows the minimum and maximum latency measured since the statistics was last
reset.
