170 Technical Specification
CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686) ID: um_t2gateway
Table B.11 Alarm Relay and Reset
Port Pin Out
PIN Connection
1 Relay 2 - Closed on alarm (NC)
2 Relay 2 Common
3 Relay 2 - Open on alarm (NO)
4 Prepared for +5 V Output
5 Ground
6 Alarm Relay - Closed on alarm (NC)
7 Alarm Relay Common
8 Alarm Relay - Open on alarm (NO)
9 Optional Reset Input
B.6 External reference
B.6.1 10MHz/1 PPS input
Connector type BNC 50 Ω socket
B.7 Compliance
B.7.1 Safety
The equipment has been designed to meet the following safety requirements: Table B.12.
Table B.12 Safety requirements met.
EN60950 (European) Safety of information technology equipment including business equipment.
IEC 60950 (International) Safety of information technology equipment including business equipment.
UL 1950 (USA) Safety of information technology equipment including business equipment.
B.7.2 Electromagnetic compatibility - EMC
The equipment has been designed to meet the following EMC requirements:
EN 55022 and AS/NZS 3548 (European, Australian and New Zealand)
Emission Standards Limits and methods of measurement of radio frequency interference
characteristics of information technology equipment - Class A.
