WEB Interface 113
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
Table
The type of information table and (in braces, []) the PID containing it.
TID
The table ID.
Primary
The primary extension ID of the table. Hovering the mouse cursor over the value displays
a tool tip describing the meaning of this key in the context of the table.
Secondary
The secondary extension ID of the table. Hovering the mouse cursor over the value displays
a tool tip describing the meaning of the secondary ID in the context of this table.
Tertiary
The tertiary extension ID of the table. Hovering the mouse cursor over the value displays
a tool tip describing the meaning of the key in the context of this table.
Ver
This is the last received version of this table.
Age
The time elapsed since the table was last updated. Selecting a single table from the tree to
the left or double clicking a line within the table opens a view displaying the parameters
of that table. The parameters are the same as are shown in the table view.
8.5.2.8 Settings
In this sub page it is possible to select the table types to analyse. Each table type has a cor-
responding check box. EIT Actual and EIT Other are further configurable as they allow the
number of days worth of data to be configured.
To commit changes to the settings on this page, click the Apply button located at the bottom of
the page. Press Refresh to reload the settings which may have been changed by another user.
Figure 8.62 shows the page as displayed in DVB mode.
In ATSC mode the page looks different, as shown in figure 8.63
Note: Turning off analysis of certain tables may impact the output stream.
Please make sure none of the tables you turn off analysis for are used by
the output. See below for examples.
Examples:
• To be able to see the programs and do service filtering on an input port you must
analyse at least PAT and PMT.
• To use the Playout Unchanged mode to play out a table on the output the table must
be analysed on the selected input.
