Short Product Description 15
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
3.2 Software options
The CP560 functionality depends on the sofware licences installed. The following table describes
the features available as software options. Please refer to Section 8.4.8.3 for more information
how to obtain and enable feature upgrades.
Table 3.1 Functionality enabled through software licences
Functionality Max value Description
SFP module - Enables operation of the Small form-factor pluggable (SFP) tranceiver slot.
SFP configuration - Enables configuration interface and parameter storage for some specifically
supported SFP modules.
Number of PLPs activated 8 Maximum number of PLPs (Physical Layer Pipes).
Number of input
ports activated
16 Controls the number of simultaneously activated transport stream inputs.
Joint bit rate control - Controls if the Joint Bit Rate Control feature is activated for sending PLP
bitrate over SNMP to other devices.
Input switching - Enables creation of input switching groups.
Forward Error Correction - Controls availability of the FEC feature for IP outputs and IP inputs.
Ethernet data interface - Controls whether carriage of MPEG transport streams on Ethernet is made
available.
Emergency switch
support
- Enables support for external switch panel to switch between pre-loaded
configurations.
DVB-T2 SFN - Enables SFN synchronisation for T2 systems.
Allow ASI inputs - Enables use of ASI input ports. Without this key the device can be used with
IP input only.
Connect control - Enables supervision of the unit through the Connect Software.
