Technical Specification 169
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
B.4.3 Ethernet data port
Table B.7 Ethernet
Data Port Specification
Type 10/100/1000Base-T
Connector type RJ45
Table B.8 Optional SFP Ethernet Data Port Specification
Type Gigabit Ethernet, Small Form-Factor Pluggable (SFP) slot to carry copper or optical SFP, compatible with
approved modules conforming to the Small Form-factor Pluggable Transceiver Multi Source agreements (Sept.
14, 2000).
B.4.4 Serial USB interface
Table B.9 USB
port specification
USB 1.1
Compatible with USB 2.0
Mini USB Connector
B.5 Alarm ports
B.5.1 Alarm relay/reset port specification
Table B.10 Alarm Relay and Reset Port
Specification
Connector type 9-pin DSUB Male
Relay rating 0.1 A max, 50 VDC max
Relay minimum load 10 µA at 10 mVDC
Reset activation time 8 seconds
