168 Technical Specification
CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686) ID: um_t2gateway
B.3.2 DC supply
Table B.3 DC Power
Supply Specification
Rated voltage 48 VDC
Voltage tolerance limits 36-72 VDC
Power consumption < 60 W
Table B.4 Physical details
Pin Placement Specification
1 top + (positive terminal)
2 middle - (negative terminal)
3 bottom Chassis Ground
B.4 Input/output ports
B.4.1 DVB ASI port
Table B.5 ASI Port Specification
Type ASI-C, Coaxial cable
Connector type BNC 75 Ω socket
Signal Compliant with ETSI EN 50083-9 (DVB A010 rev.1)
Line rate 270 Mbit/s +/- 100 ppm
Data rate 0.1 - 213 Mbit/s
Packet length 188 or 204 bytes
Max cable length (Belden 8281 type) 300 m typical
B.4.2 Ethernet management port
Table B.6 Ethernet Management Port
Specification
Type 10/100Base-T
Connector type RJ45
