Physical Description 33
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
Table 6.6 Ethernet management port LEDs
LED indicator Location Description Colour
Speed Left Unlit = 10 Mbit/s, Lit = 100 Mbit/s Green
Traffic and link Right Lit=Link, Blink=data tx or rx Green
Table 6.7 Alarm/Reset
connector pin out
Pin Function
1. Relay 2 - Closed on alarm (NC)
2. Relay 2 Common
3. Relay 2 - Open on alarm (NO)
4. Prepared for +5V Output
5. Ground
6. Alarm Relay - Closed on alarm (NC)
7. Alarm Relay Common
8. Alarm Relay - Open on alarm (NO)
9. Optional Reset Input / GPI
For more details regarding the alarm relay, please refer to Appendix on Technical Specifications
B.
6.1.12 Serial USB interface
USB interface:
• USB 1.1
• Mini USB connector
The USB interface requires a special COM port driver on the PC that shall communicate with
the device. This driver is provided on the product CD shipped with the device. The USB
interface is intended for initial IP address setup.
