152 Examples of Use
CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686) ID: um_t2gateway
− Modulation: 64-QAM
• DVB-T2 Frame
− Preamble format: SISO
− Extended carrier mode: Enabled
− FFT size: 32K
− Guard interval: 1/128
− PAPR reduction: None
− Pilot pattern: PP7
− Num DVB-T2 frames: 2
− Num OFDM symbols: 60
• Timestamp
− Timestamp type: Null
− Estimated transmission time: 1000
PLP configuration
• PLP Settings
− Input port: ASI 1
− Payload type: TS
− PLP mode: High Efficiency
− Group id: 0
− Modulation: 256-QAM
− Rotated constellation: Enabled
− FEC type: 64K LDPC
− Code rate: 2/3
− Time interleaving type: One DVB-T2 Frame
− Time interleaving length: 3
− ISSY: Disabled
− Null packet deletion: Disabled
The input TS stream will now be encapsulated and sent over the T2-MI interface to a modulator
which will transmit this on air.
10.4 SFN operation
