WEB Interface 71
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
Metric
The metric of the routing rule. If more than one rule matches a destination address the
rule with the lowest metric will be used.
When an IP packet is sent from the unit the destination address of the packet is matched against
the configured routing rules. If the destination address matches one or more rules the rule with
the lowest metric will be used. The packet will then be forwarded to the interface determined
by this rule. If the destination address is on a different subnet than the configured interface the
packet will be sent to the gateway determined by the rule.
Below the table is a checkbox where the user can Allow IP forwarding. If enabled incoming TCP
packets that are not addressed to the unit will be forwarded to an interface according to the
routing rules. The receiving interface must have management traffic enabled to forward TCP
traffic to a different interface.
Note: Modifying the IP routing rules may cause loss of contact with the
unit. Make sure you will still be able to contact the unit with the new
settings before applying the changes.
8.4.5.3 TXP Settings
Figure 8.26 TXP Settings
TXP is a T-VIPS proprietary HTTP/XML based protocol designed to retrieve configuration and
status information using WEB/HTTP requests. TXP exists side by side with an SNMP agent and
provides an alternative way to access data in a product. TXP and SNMP therefore complement
each other.
This page contains settings to determine how the unit should respond to TXP queries.
Mode
Controls the mode of the TXP server. If set to Disabled, all TXP accesses are disabled.
Anonymous read
Selects whether read accesses should be allowed without entering user credentials. This
may only be edited if Mode is different from Disabled.
Require HTTP POST for txp_set
Recommended to reduce risk of unwanted configuration changes.
