MISO group
Enable sending of MISO group parameter. Used to group the modulators into MISO group
1 or 2.
TX-Freq Offset
Select if individual addressing frame with Transmitter Frequency Offset is to be sent. User
must specify Frequency Offset.
TX-Time Offset
Select individual addressing frame with Transmitter Time Offset is to be sent. User must
specify Time Offset.
TX-Power
Select if individual addressing frame with Transmitter Power is to be sent. User must
specify Power .
Private Data
Select if individual addressing frame with Private Data is to be sent. User must specify
Private Data as hexadecimal string.
Cell Id
Set the Cell Id of the transmitter.
L1-ACE PAPR
Select if individual addressing frame with ACE (Active Constellation Extension) parameter
for the L1-signaling is to be sent. User must specify value of Max correction.
ACE PAPR
Select if individual addressing frame with ACE (Active Constellation Extension) parameter
is to be sent. User must specify Gain, Max Extension and Clipping threshold.
Tone Reservation
Select if individual addressing frame with Tone Reservation parameter is to be sent. User
must specify Clipping threshold and Number of iterations.
TX-SIG FEF stream
Select if the transmitter ID using FEF frames is to be sent. User must specify TX-SIG 1 and
TX-SIG 2.
8.6.4.6 Future Extension Frames configuration
On this page the user can set up sending of Future Extension Frames in the DVB-T2 signal
according to
[9]: ETSI EN 102 773 and [10]: DVB Document A150. Currently the implementation
only support FEF part Composite with FEF sub-part TX-SIG. This must be used in conjunction
with Individual Addressing with TX-SIG 1 and TX-SIG 2. See section 8.6.4.5.
Enable
Enable FEF part insertion in the T2 stream.
Interval
Number of T2-Frames between each FEF part. This interval must be such that a whole
