46 WEB Interface
CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686) ID: um_t2gateway
Software version
The version of the software currently installed on the device. The software version is given
by the following syntax:
<major_version>.<minor_version>.<patch_version>
The convention for the SW version numbering is as follows:
major_version
Incremented for significant SW changes.
minor_version
Incremented for minor changes. The minor version number is even for official retail
releases and odd for beta releases.
patch_version
If minor_version is even, patch_version gives the patch level of that version. A patch
level of zero means the SW is built on the latest code base, an even patch_version
means this is a released SW patch on a previous release. An odd patch_version means
that this is a test version. If minor is odd, this is a beta version, and the patch_version
simply gives the build number.
Software build time
Reports the time of which the current release image was built.
Device up time
The amount of time that has passed since the device was last reset.
Internal temperature
This shows the current internal temperature of the unit in degrees Celsius and Fahrenheit.
Fan speed
This bar chart shows the current speed of the device fans relative to full speed.
Flash Power LED button
The Flash Power LED button activates flashing the green power LED on the device in
question. This is useful for identifying which device is currently being configured. Each
click of the button extends the blinking period by five seconds up to a maximum of about
30 seconds of blinking.
8.4.2 Alarms
The Alarms page is shown in Figure 8.9:
This page displays the status of all system alarms and allows the user to program the severity
of these alarms. Global alarm configuration is performed on this page, as well as alarm relay
configuration and alarm log configuration.
It gives access to the following sub pages:
• Device Alarms
• Global configuration
