WEB Interface 115
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
Turning off analysis can free up CPU power and memory that may be used for other processing.
E.g. if PID 18 is high bandwidth, but is not interesting for analysis, then it could be beneficial
to disable EIT analysis (EITpfa, EITpfo, EITsa, EITso). In the Table Timeout Settings field it is
possible to change the timeouts used when detecting the presence of each table. The values are
specified in number of seconds.
Configuring larger time-out tolerances for tables that are occurring with non-standard repetition
intervals can reduce the number of alarms generated. Right-clicking each timeout parameter
and selecting Set to default resets the original value.
The timeout values are also used to generate Table missing alarms.
8.5.2.9 Sources
Figure 8.64 Non-standard
table source PID configuration.
This page allows you to configure non-standard input PID values for the section filtering of
individual SI/PSIP tables. This makes it possible to filter out “SDT other” on a PID of choice,
while “SDT actual” is filtered on e.g. the default PID 17. “SDT other” can then be played out
with the SI player and merged with “SDT actual” info on PID 17 on the output.
The page is shown in figure 8.64 and contains a grid with the following columns:
Table
The table type to configure with its table ID in decimal in brackets.
Source PID
The input PID to use in the section filter for this table ID. Click the grid cell to edit it.
Edited fields are shown in yellow until applied.
