Validation of DVB-T2 Parameters 185
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
Appendix E Validation of DVB-T2 Para-
meters
This chapter lists data used for DVB-T2 parameter validations.
E.1 T2-Frame
The following validations applies to the T2-Frame structure.
E.1.1 T2-Base
Tables E.1 and E.2 shows which Pilot Patterns that are allowed for a given combination of FFT
and Guard Interval. For table cells without any Pilot Patterns, the combination of FFT size and
Guard interval is not allowed.
Table E.1 SISO: Valid Pilot Patterns for
combinations of FFT size and Guard Interval
1/32 1/16 1/8 1/4 1/128 19/128 19/256
32k PP4,PP6 PP2,PP4,PP8 PP2,PP8 PP7 PP2,PP8 PP2,PP4,PP8
16k PP4,PP6,PP7 PP2,PP4,PP5,PP8 PP2,PP3,PP8 PP1,PP8 PP7 PP2,PP3,PP8 PP2,PP4,PP5,PP8
8k PP4,PP7 PP4,PP5,PP8 PP2,PP3,PP8 PP1 PP7 PP2,PP3,PP8 PP4,PP5,PP8
4k PP4,PP7 PP4,PP5 PP2,PP3 PP1
2k PP4,PP7 PP4,PP5 PP2,PP3 PP1
1k PP4,PP5 PP2,PP3 PP1
Table E.2 MISO: Valid Pilot Patterns for combinations of FFT size
and Guard Interval
1/32 1/16 1/8 1/4 1/128 19/128 19/256
32k PP4,PP8 PP2,PP8 PP4,PP6,PP8 PP2,PP8
16k PP4,PP5,PP8 PP3,PP8 PP1,PP8 PP4,PP5,PP8 PP1,PP8 PP3,PP8
8k PP4,PP5,PP8 PP3,PP8 PP1 PP4,PP5,PP8 PP1,PP8 PP3,PP8
4k PP4,PP5 PP3 PP1
2k PP4,PP5 PP3 PP1
1k PP3 PP1
