110 WEB Interface
CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686) ID: um_t2gateway
1. This icon is shown if there is an active CC error alarm related to the PID.
2. This icon is shown if the PID is a PCR PID.
3. This icon is shown if the PID is scrambled and the scrambling bit is odd.
4. This icon is shown if the PID is scrambled and the scrambling bit is even.
5. This icon is shown if the PIDs priority bit is set.
PID
This is the packet stream id.
Type
This is the packet stream type. Unsignalled PIDs have no type.
Bitrate
This is the current bitrate of the packet stream in Mbit/s.
Min Rate
This is the minimum rate of the packet stream in Mbit/s since the last rate reset.
Max Rate
This is the maximum rate of the packet stream in Mbit/s since the last rate reset.
CCErr Cnt
This is a counter which shows the number of Continuity Count errors on this packet stream
since the last CC error count reset.
Ref. by Service
This is a list of services referencing the PID. If there are too many services to show in the
cell, holding the mouse over the cell will show a tool tip with all the services.
ECM PID(s)
This is a list of ECM packet streams containing descrambling information for this PID.
Count
Number of packets counted for this packet stream since last couter reset.
Beneath the PID table are three buttons:
Reset CC error counts
This resets the CC error counters for all packet streams.
Reset min/max rates
This button resets the min and max bit rate measurements for all packet streams.
Reset packet counts
This button resets the packet counters for all packet streams.
The PID rate view is shown in figure 8.60. To the left is the bar chart showing the PIDs and
