Enable
Enable/Disable the switch as a source. When disabling the switch, no data will be for-
warded to the output from the switched input.
Label
A user spesified name for this switch.
Automatic switch
Enable/disable auto-switching. If turned on, automatical switching will happen according
to switching rules. The switch will always select the highest prioritized input that is valid.
Valid input are in sync and does not have a Critical alarm condition. If disabled, switching
is only done manually by selecting port and pressing Switch To. If disabled, the alarm
Auto switching disabled will be set to warn that no auto-switching will happen. If disabled
the unit will remember the selected input, even during power loss.
Switch wait
Time to wait before switching, in case switching condition disappears. Given in seconds
with decimals, but resolution is currently 0.5 seconds. Set this to 0 for fastest possible
switching.
Return wait
Return wait activated when switching away from a port. It will not be possible to return to
a port before Return wait seconds has passed. The return wait is a state for each input, so
it will be possible to auto-switch to other ports that has not recently been switching away
from. The return wait period can be used to avoid frequent switching between inputs.
Status
Shows current state, Idle, Active, Wait or Hold with some timing information.
Selected input
The currently selected input.
Automatic switches
Number of automatic switches performed since Reset Stats was last activated. When a
switch has been done, an alarm event can be found in the alarm log.
Manual switches
Number of manual switches performed since Reset Stats was last activated. When a switch
has been done, an alarm event can be found in the alarm log.
Switch Input Configuration
List of inputs pertaining to the switch group. Columns are:
Input
Name of the input port
Status
Input alarm status
Valid
Status of input saying if the input will be considered as valid when performing an
