WEB Interface 79
ID: um_t2gateway CP560 DVB-T2 Gateway User’s Manual Rev. 2.2 (3686)
Description
An snapshot descriptive text can be entered in this field by clicking on the field itself and
typing text. The length of this field is limited to a maximum of 64 characters.
Date saved
Time stamp when the configuration was uploaded to the unit.
File size
Size of the configuration file.
State
Full
Indicates that the configuration is a snapshot that was taken using the Snapshot utility,
storing a backup of the local system.
Loaded
Indicates that the snapshot was uploaded to the device from a PC.
To the right of the tables several buttons are provided to perform actions on the snapshots:
Activate
Loads the selected snapshot as the active configuration of the device. The administrator
will be prompted to verify the decision as this action will overwrite any unsaved changes
on the device.
Snapshot
Stores the current running configuration as a snapshot in the slot selected in the snapshot
table. This operation will overwrite the snapshot currently stored in that position without
prior notification.
Upload
Import a locally stored configuration file.
Validate
The validation process is done automatically during upload. The button is therefore dis-
abled.
Delete
Delete the entry selected in the snapshot list.
Refresh
Reload the list.
At the bottom of the page is the Results of last config action field, which will show the result
of the last action performed.
