TB30s SIP Administrator Guide v1.3 Page 56 of 259
option tftp-server-name "@IP serveur TFTP"; --------------> option 66
option bootfile-name "nomDeFichierINF.txt"; --------------> option 67
option provision-server-ip code 150 = text; ------------->option 150 is text, not binary mode
option provision-server-ip "@IP serveur TFTP "; -------------> next server address
option vendor-encapsulated-options "http://192.168.70.10/swupgrade_TB30m.txt" ---->option 43
Installation of the platform
Installation of the DHCP server
To set up all the necessary options (option 66 and 67)
Installation of the TFTP server
To put in the repertory of the TFTP server the last version of the firmware
Provisioning process
Process of auto provisioning in the theory:
At the time of the connection of a phone to the network, it will ask an IP address to DHCP
server. This one will provide him an IP address but also the address of TFTP server where file
INF is. This file will indicate on the phone the configuration file names which it must upgrade.
Process of auto provisioning in the practice:
1. Do not connect the phone with electricity. To put the cable (RJ45) in the Ethernet LAN
port at the back of the phone.
2. Restore the default parameters. With this intention, it is necessary to maintain inserted
the keys "headset" (ear-phone) and "transfers" (dumb) of the phone.
3. Connect phone with electricity.
Maintain the keys "headset" (ear-phone) and "transfers" (dumb) of the phone inserted,
until seeing that the provisioning is carried out.
4. The phone will start (it will recover an IP address by DHCP server, the IP address of
TFTP server and the name of file INF which will be downloaded) and will begin the
process of auto provisioning.
