Appendix D: Menu Bar Commands
D-6
TDS5000 Series User Manual
Display Commands
Table D--6 lists the commands available from the Display menu.
Table D- 6: Display menu commands
Submenu Command Function
Display Setup Opens the Display Setup control window, from which you can set up the display
appearance, screen text, screen objects, and screen colors.
Appearance Opens the Appearance tab of the Display Setup control window, used to set the
display style, display persistence, waveform intensi ty, display format, and
waveform interpolation.
Screen T ext Opens the Screen Text tab of the Di splay Setup control window where you can
define text captions to add to the oscilloscope display.
Objects Opens the Objects tab of the Display Setup control window, used to change the
appearance of objects on the display.
Colors Opens the Colors tab of the Display Setup control window, used to set the color
of screen objects.
Display Style Dots, Vectors,
Intensified Samples
Directly access the waveform display style options.
Display Persistence No Persistence, Infinite
Persistence, Variable
Persistence
Directly access the waveform display persistence options.
Display Format Y--T, X--Y, X--Y--Z Directly access the waveform display format options.
Display Palette
Normal,
Monochrome Gray,
Monochrome Green,
Temperature Grading,
Spect ral Grading
Directly access the waveform display palette options.
Waveform Interpola-
tion
Sin(x)/x, Linear
Choose from Sin(x)/x or Linear interpolation.
Graticule Style Full, Grid, Cross-Hair,
Frame, IRE, mV
Directly access the waveform display style options.
LCD Save Enabled Toggle the backlight timeout.
Display Date & Time Toggle the date and time display.
