Installation
1-6
TDS5000 Series User Manual
Remember to fill out and send in the customer registration card. The registration
card is packaged with this manual.
Checking the Environment Requirements
Read this section before attempting any installation procedures. This section
describes site considerations, power requirements, and ground connections for
your oscilloscope.
The oscilloscope is designed to operate on a bench or on a cart in the normal
position (on the bottom feet). For proper cooling, at least three inches (7.62 cm)
of clearance is required on the left side of the oscilloscope. The bottom and rear
require the clearance provided by the oscilloscope feet.
CAUTION. To ensure proper cooling, keep the bottom and left side of the
oscilloscope clear of obstructions.
The Specifications in Appendix A list the power source, temperature, humidity,
and altitude operating requirements for the oscilloscope.
Connecting Peripherals
The peripheral connections are the same as those on a personal computer. The
connection points are shown in Figure 1-- 1. See Table 1--2 on page 1--7 for
additional connection information.
NOTE. We recommend that you plug USB devices directly into the USB connec-
tors on the oscilloscope chassis for improved reliability rather than connecting
the devices serially. If your USB mouse locks up, disconnect and reconnect the
USB connector to restore normal operation. If the oscilloscope front panel
and/or touch screen do not respond, press the On/Standby switch for at least 5
seconds to cycle power.
Site Considerations
Operating Requirements
