Appendix D: Menu Bar Commands
TDS5000 Series User Manual
D-5
Trigger Commands
Table D--5 lists the commands available from the Trig (Trigger) menu.
Table D- 5: Trig menu commands
Submenu Command Function
A Event (Main) Trig-
ger Set up
Opens the Trigger Setup control window, used to set up the A Event triggers.
Quick Select Edge, Glitch, Width,
Runt, Window, Timeout ,
Transition, Setup/Hold,
Logic Pattern,
Logic State, Video
Opens the control window for each of these trigger types.
Edge Setup Opens the Trigger Setup control window for the Edge trigger type.
Glitch Setup Opens the Trigger Setup cont rol window for the Glitch trigger type.
Width Setup Opens the Trigger Setup cont rol window for the Width trigger type.
Runt Setup Opens the Trigger Setup control window for the Runt trigger type.
Window Setup Opens the Trigger Setup control window for the Window trigger type.
Timeout Setup Opens the Trigger Setup control window for the Timeout trigger type.
Transition Setup Opens the Trigger Setup control window for the Transition trigger type.
Setup/Hold Setup Opens the Trigger Setup control window for the Setup/Hol d trigger type.
Logic Pattern Opens the Trigger Setup control window for the Pattern trigger type.
Logic State Opens the Trigger Setup control window for the State trigger type.
Video Setup Opens the Trigger Setup control window for the Video t rigger type.
A-B Trigger Sequence Opens the Trigger Setup control window to set up A--B sequence triggering.
B Event (Delayed) Trig-
ger Setup
Opens the Trigger Setup control window to set up the selected the B trigger
type.
Holdoff Opens the Holdoff control window, used to set trigger holdoff.
Mode Opens the Mode control window, used to select the trigger mode, force a trigger,
and set the trigger level to 50%.
Run/Stop Opens the Run/Stop control window you can use to start and stop acquisitions,
control a single sequence of acquisi tions, and display the acquisition st atus.
