TDS5000 Series User Manual
A-1
Appendix A: Specifications
This appendix contains the specifications for the TDS5000 series Digital
Phosphor Oscilloscopes. All specifications are guaranteed unless labeled
“typical.” Typical specifications are provided for your convenience but are not
guaranteed.
All specifications apply to all TDS5000 models unless noted otherwise. To meet
specifications, the following conditions must be met:
H The oscilloscope must have been calibrated in an ambient temperature
between 20 °C and 30 °C(68°F and 86 °F).
H The oscilloscope must be operating within the environmental limits listed in
Table A--10 on page A--20.
H The oscilloscope must be powered from a source that meets the specifica-
tions listed in Table A-- 8 on page A--18.
H The oscilloscope must have been operating continuously for at least 20
minutes within the specified operating temperature range.
H You must perform the Signal Path Compensation procedure after the
20-minute warm-up period, and the ambient temperature must not change
more than 5 °C(41°F) without first repeating the procedure. See Appendix
E: Optimizing Measurement Accuracy for instructions to perform this
procedure.
Product and Feature Description
The TDS5000 Series Digital Phosphor Oscilloscope family consists of the
models shown in Table A-- 1.
Table A- 1: TDS5000 models
Model
Number of
channels
Bandwidth
Maximum sample
rate (real time)
TDS5052 2 500 MHz 5 GS/s
TDS5054 4 500 MHz 5 GS/s
TDS5104 4 1GHz 5 GS/s
