Data Input and Output

3- 194

TDS5000 Series User Manual

You can clear individual references or delete waveform files. Use this procedure

when you are certain that you no longer need the data in these files. To clear all

references and setups, use the Utilities menu Tek Secure Erase command.

Overview To clear references Control elements and resources

Prerequisites

1. The oscilloscope must be powered on. You must have

access to a waveform saved by the oscilloscope.

See Powering O n the Oscilloscope on page 1--8,

and Saving a Waveform on page 3--190

Display the

Reference

Setup control

window

2. From the toolbar, cli ck Refs and select the tab of the

reference you want to delete.

Delete the

reference

3. Click Delete to delete the reference waveform.

Clearing References
