Tektronix TDS5052 User Manual

Appendix A: Specifications
A-18
TDS5000 Series User Manual
Table A- 6: Input/output por t specifications (Cont.)
Characteristic Description
Side-panel I/O ports Ports located on the rear panel
Parallel port (IEEE 1284) DB-25 connector, supports the following modes:
-standard (output only)
bidirectional (PS-2 com patible)
bidirectional enhanced parallel port (IEEE 1284
standard, mode 1 or mode 2, v 1.7)
-bidirectional high-speed extended capabilities
Audio ports Miniature phone jacks for stereo microphone input and
stereo line output
USB port (2) Allows connection or disconnection of USB keyboard,
mouse and/or other devices while scope power is on
Keyboard port PS-2 compatible, oscilloscope power must be off to make
connection
Mouse port PS-2 compatible, oscilloscope power must be off to make
connection
LAN port RJ-45 connector, supports 10 base-T and 100 base-T
Serial port DB-9 COM1 port, uses NS16C550-compatible UARTS,
transfer speeds up to 115.2 kb/s
SVGA video port Upper video port, DB-15 female connector, connect a
second monitor to use dual-monitor display mode,
supports Basic requirements of PC99 specifications
GPIB port IEEE 488.2 standard interface
Scope VGA video port Lower video port, DB-15 female connector, 31.6 kHz
sync, EIA RS-343A compliant, connect to show the
oscilloscope display, including live waveforms, on an
external monitor
Table A- 7: Data storage specifications
Characteristic Description
CD-ROM Side-panel CD-ROM drive, read only. CD--RW optional
Floppy disk Front-panel 3.5 in floppy disk drive, 1.44 MB capacity
Hard disk Internal hard disk drive, ≥ 20 GB capacity
