Tektronix TDS5052 User Manual

Appendix A: Specifications
TDS5000 Series User Manual
A-21
Table A- 11: Certifications and compliances
Category Standards or description
EC Declaration of Conformity --
EMC
Meets intent of Directive 89/ 336/EEC for Electromagnetic Compatibility. Compliance was
demonstrated to the following specifications as listed in the Official Journal of the European Union:
EN 61326 Emissions
1, 3
Class A Radiated and Conducted Emissions
EN 61326 Immunity
1, 2, 4
IEC 61000-4-2 Electrostatic Discharge Immunity
±4 kV contact discharge, ±8 kV air discharge,
performance criterion C
IEC 61000-4-3 RF field immunity
3V/m,80MHzto1GHz,
80% amplitude modulated witha1kHzsinewave
performance criterion A
IEC 61000-4-4 Electrical Fast Transient/Burst Immunity
1 kV on AC mains, 500 V on !/O cables, performance criterion C
IEC 61000-4-5 AC Surge Immunity
500 V differential mode, 1 kV common mode,
performance criterion B
IEC 61000-4-6 RF Conducted Immunit y
3 V, 150 kHz to 80 MHz, amplitude modulated with a
1 kHz sinewave, performance criterion A
IEC 61000-4-11 AC Mains Volt age Dips and Interruption Immunity
100% reduction for one cycle, performance criterion B
EN 61000-3-2 Power Harmoni c Current Emissions
1
If interconnect cables are used, they must be low-EMI shielded cables such as the following
Tektronix part numbers or their equi valents: 012-0991-01, 012-0991-02 or 012-0991-03 GPIB
Cable; 012-1213-00 (or CA part number 0294-9) RS-232 Cable; 012-1214-00 Centronics
Cable; or LCOM part number CTL3VGAMM-5 VGA Cable.
2
The performance criteria for when the oscilloscope is subjected to the conditions described
above are defined as follows:
A—≤0.2 division waveform displacement or ≤0.4 division increase in peak-to-peak noise
B — temporary, sel f-recoverable degradation or loss of performance is allowed, but no change
of actual operating state or loss of stored data is allowed
C — temporary l oss of function is all owed provided that the function is sel f recoverable or can
be restored by the operation of the controls
3
Radiated emissions may exceed the levels specified in EN 61326 when this oscilloscope is
connected to a test object.
4
USB mouse and keyboard only, performance crit erion C. Normal USB keyboard or mouse
operation can be restored by unplugging and reconnecting t he USB connector to the
oscilloscope. If the USB mouse, front-panel controls, or touch screen do not respond, press
the On/Standby switch for five seconds to cycle power.
FCC Radiated and conducted emissions do not exceed the levels specified in FCC47 CFR, Part 15,
Subpart B, for Class A equipment.
