Tektronix TDS5052 User Manual

Appendix D: Menu Bar Commands
TDS5000 Series User Manual
D-7
Cursors Commands
Table D--7 lists the commands available from the Cursors menu.
Table D- 7: Cursors menu commands
Submenu Command Function
Cursor Controls Opens the Cursor Type Setup control window, used to select the type of cursors.
Cursors On Toggles display of cursors on and off.
Cursor Type H-bars, V-bars, Paired,
Split
Enables the selected cursor type.
Cursor Mode Independent, Track Sets the selected cursor tracking mode.
Cursor Posi tion Opens the Cursor Position control window, used to position the cursors.
Cursor Set up Opens the Cursor Setup control window, used to set up and control cursors.
Measure Commands
Table D--8 lists the commands available from the Measure (Measurement) menu.
Table D- 8: Measure menu commands
Submenu Command Function
Measurement Setup Opens the Measurement Setup control window, used to set up the oscilloscope
for automatic measurements.
Snapshot Lets you see all of the automated measurements for a selected waveform at
one time.
Amplitude High Level, Low Level,
Amplitude, Maximum,
Minimum, Peak to Peak,
Pos Overshoot,
Neg Overshoot, Mean,
RMS, Cycle Mean,
Cycle RMS
Selects the individual automatic amplitude measurement directly without
opening the Measurement Setup control window.
Time Rise Time, Fall Time,
Positive Width,
Negative Width, Period,
Frequency, Delay,
Pos Duty Cycle,
Neg Duty Cycle
Selects the individual automatic time measurement di rectly without opening the
Measurement Setup control window.
More Area, Cycle Area, Phase,
Burst Width
Selects the individual automatic measurement directly without opening the
Measurement Setup control window.
