Appendix A: Specifications
A-16
TDS5000 Series User Manual
Table A- 4: Trigger specifications (Cont.)
Characteristic Description
Runt or Window type, wider
than
1nsto1s
Runt or Window type, time
qualified
1nsto1s
Width type 1nsto1s
Timeout type 1nsto1s
Transition type 1nsto1s
Pattern type 1nsto1s
Setup/Hold type Setup and Hold timers Limits
Setup time (time from data
transition to clock edge)
--100 ns to +100 ns
Hold time (time from clock
edge to data transition)
--1 ns to +100 ns
Setup time + Hold time
(algebraic sum of the two
settings)
+2 ns to +200 ns
Advanced trigger timer accuracy For Glitch, Timeout, or Width types
Time range Accuracy
1 ns to 500 ns ±(20% of setting + 0.5 ns)
520 ns to 1 s ±(0.01% of setting +
100 ns)
Trigger holdoff range 1.5 µsto12s,
minimum resolution is 8 µs for settings ≤1.2 ms
Table A- 5: Display specifications
Characteristic Description
Display type 211.2 mm (8.3 in) width × 158.4 mm (6.2 in) height , 264
mm (10.4 in) diagonal, liquid crystal active-matrix color
display
Display resolution 640 horizontal × 480 vertical pixels
Pixel pitch 0.33 mm horizontal, 0.33 mm v ertical
Contrast ratio, typical 150:1
Response time, typical 50 ms, black to white
Display refresh rate 59.94 f rames per second
Displayed intensity levels Supports Windows SVGA high-color mode (16- or 24-bit)
