Tektronix TDS5052 User Manual

Product Description
1-4
TDS5000 Series User Manual
Probes Supported
Table 1--1 lists the recommended probes for each oscilloscope. Descriptions of
each probe follow the table.
Table 1- 1: Recommended probe cr oss ref erence
Probe TDS5052 TDS5054 TDS5104
Passive, 10X P5050 P5050 P5050
Passive, 100X P5100 P5100 P5100
Passive, 1000K P6015A P6015A P6015A
Active CMOS/TTL P6243 P6243 P6245
All Technology P6245 P6245 P6245
Differentia l Digital P6246,
P6247,
P6248
P6246,
P6247,
P6248
P6246,
P6247,
P6248
High Voltage Differential P5205,
P5210
P5205,
P5210
P5205,
P5210
Current, AC Only CT-6 CT-6 CT-6
Current, AC/DC TCP202 TCP202 TCP202
Low Capacitance P6158 P6158 P6158
H P5050 10X, 500 MHz passive probe
H P5100 100X, 250 MHz passive high voltage probe
H P6015A 1000X, 100 MHz passive high voltage probe
H P6243 Active, high speed digital voltage probe, FET, DC to 1.0 GHz
H P6245 Active, high speed digital voltage probe, FET, DC to 1.5 GHz
H P6246 Active, high bandwidth differential probe, FET, DC to 400 MHz
H P6247 Active, high bandwidth differential probe, FET, DC to 1 GHz
H P6248 Active, high bandwidth differential probe, FET, DC to 1.7 GHz
H P5205 Active 100 MHz differential probe
H P5210 Active, 50 MHz differential probe
H TCP202 Current Probe, DC to 50 MHz, 15 A DC
H CT-6 Current probe, designed for temporary in-circuit installation, 250 kHz
to 2 GHz, 50 Ω input
H P6158 20X, 3 GHz low capacitance probe
