Appendix D: Menu Bar Commands
D-8
TDS5000 Series User Manual
Table D- 8: Measure menu commands (Cont.)
Submenu FunctionCommand
Display Statistics Value,
Value, Mean,
Value, Statistics
Opens the selected measurement statist ics of current measurements.
Reference Levels Opens the Reference Levels control window, used to define reference levels for
the measurements.
Gating Opens the Measurement Gating control window, used to limit the measurement
area of the waveform to the region bounded by the vertical bar cursors or to the
left and right edges of the Zoom window.
Waveform Histograms
(Optional)
Opens the Waveform Histogram setup window, used to set histograms on your
waveforms. Only available if you have Option 2A, Advanced Analysis, instal led.
Reset Histograms (Op-
tional)
Resets histogram counting. Only avail able if you have Option 2A, Advanced
Analysis, installed.
Histogram Measure-
ments (Optional)
Value Count, Hits in Box,
Peak Hits, Median,
Maximum, Minimum,
Peak to Peak, Mean,
Standard Deviation,
Mean 1StdDev,
Mean 2StdDev,
Mean 3StdDev
Opens the selected measurement for the histogram. Only available if you have
Option 2A, Advanced Analysi s, installed.
Standard Math Commands
Table D --9 lists the commands available from the standard (default) Math menu.
Table D- 9: Standard Math menu commands
Submenu Command Function
Math Setup Opens the Math Setup control window, used to define and create math
waveforms.
Display On/Off Opens the Waveform Display control window, used to turn the display of
waveforms on and off.
Position/Scale Opens the Position/Scale control window, used to posit ion the waveform and set
the vertical scale.
Label Opens the Waveform Label control window, used to attach a label to the
waveform.
Magnitude Spectrum Creates a predefined magnitude spectral mat h waveform.
