AGL7 module adjustment procedures
Procedure
WARNING. To avoid serious injury, do n ot touch exposed connectors or
components when operating the TG8000 mainframe with the top cover removed.
Dangerous potentials exist at several points within the TG8000 mainframe.
1. Select the NTSC Black Burst signal for BLACK 1 and BLACK 2 and
1080/59.94i signal for BLACK 3 as follows:
a. Press the left (◄)orright(►) arrow button to select BLACK 1,andthen
press the ENTER button.
b. Press the left (◄)orright(►) arrow button to select NTSC,andthen
press the ENTER button.
c. Press the left (◄)orright(►) arrow button to select Black Burst,and
then press the ENTER button.
d. Press the BACK button twice to return the AGL7 main menu.
e. Repeat parts a through d of this step to select the NTSC Black Burst
signal for BLACK 2.
f. Press the left ( ◄)orright(►) arrow button to select BLACK 3,andthen
press the ENTER button.
g. Press the left ( ◄)orright(►) arrow button to select 1080/59.94i,and
then press the ENTER button.
h. Press the BACK button to return the AGL7 main menu.
4–8 TG8000 Multiformat Test Signal Generator Service Manual
