SDI7 module replaceable parts list
SDI7 module re
placeable parts list
This section
contains a list of the replaceable modules for the SDI7 module. Use
this list to identify and order replacement parts. For parts ordering or servicing
information, refer to the Mainframe replaceable p arts list section of this manual.
(See page 2-35.)
This section contains a list of t he replaceable parts and modules for the SDI7
module. Use this list to identify and order replacement parts.
Abbreviations
Abbreviations conform to American National Standard ANSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the SDI7 module.
Table 14-8: SDI7 module – replace able parts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
11-5-1 116-1162-00 1
MODULE ASSEMBLY; SDI7
-2 211-0408-00 8
SCR, ASSY, WSHR; 4-40 X 0.250, PNH, STEEL, ZINC FINISH, T-10 TORX DR,
SEMS
-3 878-0588-00 1
CIRCUIT BD SUBASSEMBLY; TRIGGER OUTPUT; 389409500 WIRED
-4 878-0602-00 1
CIRCUIT BD SUBASSEMBLY; SDI OUTPUT; 389409600 WIRED
-5
131-M057-00
5
CONN, RF: PCB, FEMALE, BNC, 75 OHM, EDGE LAUNCH TYPE
-6 348-1944-00 1
GAP PAD 3000S30
-7
214-5166-01 1
HEATSINK, PCB TO CHASSIS
-8 441-2555-00 1
CHASSIS, MODULE
-9 333-4663-00 1 PANEL, REAR
-10 214-4762-00 2
SPRING; CONICAL
-11 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45 MM, LENGTH 11 MM, HEAD DIA 5 MM,
HEAD HEIGHT 2 MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-12 220-0497-00 4
NUT, PLAIN, HEX; .5-28 X .562 HEX, BRS, NI (NICKEL) PLATED
-13 210-1039-00 4
WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
-14 211-0101-00 3
SCREW, MACHINE; 4-40 X 0.25, FLH, 100 DEG, ZINC PLATED STEEL, T8
-15 348-A128-00 2.5
cm
SHLD GASKET, ELEK: FINGER TYPE, 5.1 MM LX6.4 MM W, BE-CU [97-645-02]
-16 878-0580-00 1
CIRCUIT BOARD SUBASSY; SDI7 TEST SIGNAL GENERATOR, UNTESTED,
389409300 ROHS COMPLIANT
14–30 TG8000 Multiformat Test Signal Generator Service Manual
