6-14 4252490-Rev A
HYDRAULICS
6
Hydraulic Schematic (2WD),
Continued
Figure 6-10
Steering Cylinder
Steering Unit
Steering Valve
Check
Valve
TN3028
3.84
ci
1
2
8
9
6
7
RL
TP
2
9
6
7
