Symbols
11/2020 243343V03_EN 3
1.2 Symbols
1.2.1 In the operating manual
Hazard warnings and notices are clearly marked in the operating manual.
The following symbols are used:
1.2.2 On the machine
Several information signs have been attached to the machine. These signs
must be complete and legible. They can be reordered.
Type and source of hazard!
This hazard warning warns about possible personal injury.
Type and source of hazard
This hazard warning warns about damage to equipment, the
environment or other damage to property.
Note:
This symbol indicates information that is provided for better
understanding of the processes.
Electric shock
Cutting hazard
Wear cut-resistant gloves
Collect hydraulic oil
