Technical specifications
86 11/2020 243343V03_EN
10.3 Technical specifications
Description Values
Length x Width x Height Dimensions, see 10.4
Weight see rating plate
Cutting chamber cross section 120 x 120 mm
Cutting chamber length 550 mm
max. fill cross section 170 x 550 mm
Cut-off length 1 to 40 mm
(depending on the installed knife and the
set cutting unit speed)
max. effective output 1,800 kg/h
depending on product and application
Operating voltage see rating plate
Connected load see rating plate
Maximum operating pressure 110 bar
Emission sound pressure level < 76 dB (A)
in idle operation
Available grid sizes 6/8/12/17/24/30/40 mm
(other grid sizes on request)
min. temperature of product see Notes about cutting14
(other temperatures on request)
permissible ambient temperature 0 to 30 °C
Relative humidity max. 80%
(other temperatures on request)
electrical equipment Electronics
