Installing the manual feed
40 11/2020 243343V03_EN
4.8 Installing the manual feed
Assembly occurs in reverse order to dismantling
(☞ „Removing the feed“ on page 34).
Note for the installation of the guide rail:
b Insert the guide rail as far as the stop.
Attention, damage to equipment!
The guide rail must never be in contact with the fastenings
(arrows) of the feed as this can destroy the guide rail.
Make sure that the guide rail is inserted as far as the stop.
