Transport and installation
Dismantling discharge conveyor
78 11/2020 243343V03_EN
8.5 Dismantling discharge conveyor
b Disconnect the main power supply and secure it against unintended
switching on.
b Loosen the plug.
b Unplug the plug connector of the discharge conveyor drive from the
socket on the rear of the machine.
b Open the knife box door (☞ „Opening/closing the knife box door“ on
page 35).
b Remove the protective cover of the discharge conveyor.
b Turn down the roller bearing so that the transport belt is slackened.
b Remove the transport belt.
b Pull the discharge conveyor off both of the supporting rods.
