Dismantling the product stabiliser
38 11/2020 243343V03_EN
4.6 Dismantling the product stabiliser
The product stabilisers are inserted into the grooves of the upper grid.
b Pull the product stabilisers out of the upper grid.
4.7 Dismantling the grid blades
Tension principle of the grid blades
The cross bars are pushed apart by tightening the tension screws. The grid
blades are connected to the cross bars so that they are tensioned when the
cross bars are pushed apart.
