Cleaning / Disinfection

Cleaning of the separating slide

24 11/2020 243343V03_EN

3.3 Cleaning of the separating slide

b Grip the cross bar and pull the separating knife to the front.

b Set up separating slide.

b Remove lower guide rail.

01053 / 0

01054 / 0

AM_0013
