Set-up
4. Set-up
This chapter is intended for the personnel who set up the machine.
The information and instructions required for setting up the machine can be
found here.
This chapter covers the following:
Removing the feed................................................................................ 34
Opening/closing the knife box door ...................................................... 35
Dismantling the cut-off knife ................................................................. 35
Dismantling the grating disc or stop disc (optional) .............................. 36
Dismantling the cutting unit................................................................... 37
Dismantling the product stabiliser......................................................... 38
Dismantling the grid blades .................................................................. 38
Installing the manual feed ..................................................................... 40
Installing the product stabiliser ............................................................. 41
Installing the grid blades ....................................................................... 41
Installing the cutting unit ....................................................................... 43
Installing cut-off knife ............................................................................ 44
Setting the cutting gap .......................................................................... 44
Installing the grating disc or stop disc (optional)................................... 45
Adjustment of the grating disc .............................................................. 46
Dismantling / installing the hygiene strip............................................... 50
Dismantling / installing the scraper ....................................................... 50
Safety instructions for set-up
Danger
Risk of fatal injury from electric shock!
The main power supply must be interrupted and secured
against unintended switching on during all installation work on
the machine as soon as the type of work allows to do so:
b Unplug the mains plug and put in a safe place.
Attention
Risk of injury to persons and damage to equipment!
Incorrect set-up of the machine may cause it to malfunction and
thus endanger the personnel.
The following therefore always applies for set-up:
 The machine may only be set up by trained and authorised
specialist personnel.
 Do not put the machine into operation until all set-up compo-
nents have been adjusted and coordinated as described.
