Dismantling the grating disc or stop disc (optional)
36 11/2020 243343V03_EN
4.4 Dismantling the grating disc or stop disc (optional)
b Using the supplied spanner, loosen the central lock until the grating
disc or stop disc is sitting loosely on the knife shaft.
b Hold the grating disc on the handles as shown and pull it from the knife
shaft (the same applies for the stop disc).
b Put the grating disc or stop disc in a safe place.
Attention, high risk of cutting yourself on the stop disc and
on the grating disc!
Always wear the mandatory protective equipment when carry-
ing out work in the open cutting chamber and when handling the
grating discs or stop discs (☞ „Protective equipment“ on page
4).
Only store dismantled grating discs or stop discs in secured
places.
