Removing the feed
34 11/2020 243343V03_EN
The following applies for the dismantling and assembly descriptions below:
The machine is in the cleaning position. (☞ „Cleaning mode“ on page
19).
The main power supply is disconnected and secured against uninten-
tional switching on.
The knife box door is open.
4.1 Removing the feed
b Remove cutting plate from the filling pan.
b Put the separating slide in the cleaning position. (☞ „Cleaning of the
separating slide“ on page 24).
b Remove lower guide rail.
b Removed insert 1 from the chamber upwards.
b Lift the piston plate up and off.
